BAIXIANG MOTOR CO.,LTD.
W.E1050R/W.E2050R
Volt：12V 24V
No-load current：2.6A ≤1.5A
No load speed： 50±10%rpm
Load current：≤13A/≤7A
Load speed：40±5%rpm
Working torque：7.5N.m
Brake torque：≥27N.m
Intensity of the gear：≥25N.m
Working temperature：-20℃~60℃
Noise：≤55dB
Direction of rotation: Red wire+ Clockwise Rotation (CW)
Green wire+ Counter Clockwise Rotation(CCW)
No-load current：2.6A ≤1.5A
No load speed： 50±10%rpm
Load current：≤13A/≤7A
Load speed：40±5%rpm
Working torque：7.5N.m
Brake torque：≥27N.m
Intensity of the gear：≥25N.m
Working temperature：-20℃~60℃
Noise：≤55dB
Direction of rotation: Red wire+ Clockwise Rotation (CW)
Green wire+ Counter Clockwise Rotation(CCW)
| Volt | 12V | 24V |
| No-load current | 2.6A | ≤1.5A |
| No load speed | 50 10%rpm | 50±10%rpm |
| Load current | ≤13A | ≤7A |
| Load speed | 40±5%rpm | 40±5%rpm |
| Working torque | 7.5N.m | 7.5N.m |
| Brake torque | ≥27N.m | ≥27N.m |
| Intensity of the gear | ≥25N.m | ≥25N.m |
| Working temperature | -20℃~60℃ | -20℃~60℃ |
| Noise | ≤55dB | ≤55dB |
| Direction of rotation: Red wire+ Clockwise Rotation (CW) Green wire+ Counter Clockwise Rotation(CCW) | ||
