BAIXIANG MOTOR CO.,LTD.
W.E1044L/W.E2044L
Volt：12V/24V
No-load current：2.5A/≤2.0A
No load speed：50±10%rpm
Load current：8A/4.5A
Load speed：40±10%rpm
Working torque：7N.m
Brake torque：22N.m
Intensity of the gear ：35N.m
Working temperature：-20℃-60℃
Noise：≤55dB
Direction of rotation: Raed wire+ Clockwise Rotation (CW)
Green wire+ Counter Clockwise Rotation(CCW)
No-load current：2.5A/≤2.0A
No load speed：50±10%rpm
Load current：8A/4.5A
Load speed：40±10%rpm
Working torque：7N.m
Brake torque：22N.m
Intensity of the gear ：35N.m
Working temperature：-20℃-60℃
Noise：≤55dB
Direction of rotation: Raed wire+ Clockwise Rotation (CW)
Green wire+ Counter Clockwise Rotation(CCW)
| Volt | 12V | 24V |
| No-load current | 2.5A | 2.0A |
| No load speed | 50±110%rpm | 50±10%rpm |
| Load current | 8A | 4.5A |
| Load speed | 40±10%rpm | 40±10%rpm |
| Working torque | 7N.m | 7N.m |
| Brake torque | 22N.m | 22N.m |
| Intensity of the gear | 35N.m | 35N.m |
| Working temperature | -20℃-60℃ | -20℃~60℃ |
| Noise | ≤55dB | ≤55dB |
| Direction of rotation: Red wire+ Clockwise Rotation (CW) Green wire+ Counter Clockwise Rotation(CCW) | ||
